Recently, while working at my previous company, I had gotten interested in packaging my Python application. The goal was to create a self-contained directory that would be able to run our application on any machine (which won’t have Python installed as well).
This turns out to be non-trivial when you have tons of imaging and AI libraries (C extensions essentially).
I ended up diving reasonably deep into the linker rabbit hole (specifically the macOS and Linux linkers), the topic of this article.

In this article, instead of starting with theory, I’m starting with practical problems we find in our day jobs related to dynamic linking and building from there.

NOTE: There are references to the Python ecosystem in this article, but the crux is really about shared libraries and how the linker finds the dependencies your application expects.
I also discuss how we can create standalone relocatable distributions when shipping applications with shared libraries. Being a Python developer should not be a prerequisite.

The problem

Most of us would have seen errors like below (I got this error while running import cv2 in Python for an older version opencv-python-headless==4.5.3.56).

ImportError: dlopen(
    /Users/hariomnarang/miniconda3/envs/linkers/lib/python3.9/site-packages/cv2/cv2.cpython-39-darwin.so, 0x0002
):
Library not loaded: /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib
    Referenced from: <5066EC51-2BC1-37AE-9BDC-A1F0C65A405B>
        /Users/hariomnarang/miniconda3/envs/linkers/lib/python3.9/site-packages/cv2/cv2.cpython-39-darwin.so
    Reason: tried:
        '/opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib' (no such file),
        '/System/Volumes/Preboot/Cryptexes/OS/opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib' (no such file),
        '/opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib' (no such file),
        '/usr/local/lib/libavcodec.58.dylib' (no such file),
        '/usr/lib/libavcodec.58.dylib' (no such file, not in dyld cache)

I’ve seen many people shoot arrows in the dark after this. We simply google these errors and try every random trick we can find. After reading this article, you would still do all of those things :), but you would know what you are doing, and might be able to go about the process in a structured way.

The above error message is coming directly from the macOS linker. It is saying that it wasn’t able to find the dependency libavcodec.58.dylib. The library cv2.cpython-39-darwin.so has this as its dependency.

Basic anatomy of compiled code

At its core, an application is simply a file in a very specific format (conventionally, all application or shared library files are called object files. The format is the same; the OS uses the file metadata to differentiate between libraries and applications).
Every OS has its own format. Linux has ELF, macOS has Mach-O. These formats are huge.
When you run an application, the OS examines the contents of this file and figures out how to “run” the code inside this application file.

The most basic way to run code is to load the contents of the executable in memory without any modifications and jump the instruction pointer to the start address of the machine code. The executable formats nowadays however, are slightly more complex. Apart from the raw code, there is a lot of metadata in these files which the OS uses. The metadata we are interested in is how these files define dependencies.

Dependencies of a Mach-O file

You can take a look at the metadata of a file using otool in macOS. I’ll inspect the first file in the stack trace above.

otool -l cv2.cpython-39-darwin.so

This command prints the Load Commands in a Mach-O file. The macOS linker dyld uses these commands to figure out how to prepare the Mach-O file for execution (how to load it).

An example entry:

Load command 7
     cmd LC_UUID
 cmdsize 24
    uuid 5066EC51-2BC1-37AE-9BDC-A1F0C65A405B

There are many different types of commands that instruct the linker about some specific metadata. The command above is of type LC_UUID, which tells the linker to get the UUID of the object file from the property uuid.

The command types we are interested in look like this

Load command 12
          cmd LC_LOAD_DYLIB
      cmdsize 80
         name /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 58.134.100
compatibility version 58.0.0

The load command above is of type LC_LOAD_DYLIB. The command tells the linker that the file at /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib is a direct dependency of this object file. The linker would load the dependency if it exists at the path.
All the LC_LOAD_DYLIB commands for my object file:

Load command 10
          cmd LC_LOAD_DYLIB
      cmdsize 56
         name /usr/lib/libSystem.B.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 1292.100.5
compatibility version 1.0.0
Load command 11
          cmd LC_LOAD_DYLIB
      cmdsize 88
         name /System/Library/Frameworks/AppKit.framework/Versions/C/AppKit (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 2022.44.149
compatibility version 45.0.0
Load command 12
          cmd LC_LOAD_DYLIB
      cmdsize 80
         name /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 58.134.100
compatibility version 58.0.0
Load command 13
          cmd LC_LOAD_DYLIB
      cmdsize 80
         name /opt/homebrew/opt/ffmpeg/lib/libavformat.58.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 58.76.100
compatibility version 58.0.0
Load command 14
          cmd LC_LOAD_DYLIB
      cmdsize 72
         name /opt/homebrew/opt/ffmpeg/lib/libavutil.56.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 56.70.100
compatibility version 56.0.0

.....a lot of more load commands

Load command 29
      cmd LC_FUNCTION_STARTS
  cmdsize 16
  dataoff 21140744
 datasize 52768
Load command 30
      cmd LC_DATA_IN_CODE
  cmdsize 16
  dataoff 21193512
 datasize 0
Load command 31
      cmd LC_CODE_SIGNATURE
  cmdsize 16
  dataoff 26235040
 datasize 205128
Load command 32
          cmd LC_RPATH
      cmdsize 144
         path /private/var/folders/b7/g6qfbypj0tq32j5_trjh516r0000gn/T/pip-req-build-_pm4jjil/_skbuild/macosx-11.0-arm64-3.9/cmake-install/lib (offset 12)
Load command 33
          cmd LC_RPATH
      cmdsize 32

This is a lot to take in. Let’s focus on the load command containing libavcodec as that’s the error we got (linker could not find this specific library). Here’s the load command:

Load command 12
          cmd LC_LOAD_DYLIB
      cmdsize 80
         name /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 58.134.100
compatibility version 58.0.0

dyld is trying to load the library libavcodec.58.dylib at /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib.

The output is very verbose. If you just want a quick glance at the dependencies, use otool -L (capital L).

Running ls /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib, I can see that it does not exist in my system. A quick Google search asks us to install ffmpeg using brew install ffmpeg.
I still get the same stack trace, the file /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib still does not exist. The directory /opt/homebrew/opt/ffmpeg/lib/ however, does exist. Running ls we see this.

$ ls /opt/homebrew/opt/ffmpeg/lib/ | grep avcodec

libavcodec.61.19.101.dylib
libavcodec.61.dylib
libavcodec.a
libavcodec.dylib

So we have the wrong version here. If we look at the download page of ffmpeg, we see that libavcodec.58 is present in ffmpeg 4.x version. We can install it using brew install ffmpeg@4.
This still does not fix the error. The problem is that the library now exists at /opt/homebrew/opt/ffmpeg@4/lib/libavcodec.58.dylib (note the ffmpeg@4 in the path). The linker is, however, looking at the path without the @4 suffix. brew has installed ffmpeg 7.x at the default location.

We could technically uninstall ffmpeg and create a symlink at /opt/homebrew/opt/ffmpeg pointing to ./ffmpeg@4.

NOTE: This is dangerous; other applications using ffmpeg@7 would start breaking.

brew uninstall ffmpeg
ln -s /opt/homebrew/opt/ffmpeg@4 /opt/homebrew/opt/ffmpeg

I get a NumPy version mismatch error, but this specific problem is solved now. opencv is able to find its dependencies.

DYLD_LIBRARY_PATH

It is unreasonable to ask users to uninstall other library versions for this case, though. What if some other application relies on ffmpeg@7 to be the default installation? There is an escape hatch: the environment variable DYLD_LIBRARY_PATH. It’s a colon-separated list of directories like PATH.

If the dependency is specified by an absolute path /opt/homebrew/opt/ffmpeg@4/lib/libavcodec.58.dylib, dyld will search for the library using its leaf name (libavcodec.58.dylib) in all the directories in DYLD_LIBRARY_PATH. If the file exists in any of these directories, it’s loaded.

The solution is to set DYLD_LIBRARY_PATH before starting the main process.

# our startup file: run.sh
export DYLD_LIBRARY_PATH="/opt/homebrew/opt/ffmpeg@4/lib/:$DYLD_LIBRARY_PATH"
python main.py

Make sure you do not set DYLD_LIBRARY_PATH in your bashrc files. This would set it globally and can affect other applications.
It’s reasonably safe to use it like this in startup scripts.

This solves our problem, opencv loads without uninstalling ffmepg@7 system-wide.

absolute paths are a problem

This opencv installation is using absolute paths for its dependency load commands. This is the reason it is so painful for us as end users to make this specific version work.
It also makes shipping very annoying. We can’t hope the end user would have some dependency installed at an exact location we want. It is also risky to ship the dependencies at those exact locations, as they might conflict with existing software in the user’s machine (as ffmpeg@4 conflicted with ffmpeg@7 in my machine).
The solution is to provide libraries with all the dependencies contained in the distribution without conflicting with existing software by using rpaths.

NOTE: You could use DYLD_LIBRARY_PATH to ship too (simply put all dependencies in one directory in your distribution, and set the environment variable in your startup script before calling your main program). This does not work, though; I’ll come to this problem later in the article.

@loader_path, @executable_path

Let’s update opencv, and also remove ffmpeg :)

# remove dependencies
brew uninstall ffmpeg
brew uninstall ffmpeg@4


# update package
pip install opencv-python-headless opencv-python --upgrade

If you run the main program, the code would run without any problems! What happened?

Let’s look at the dependencies of the shared library this version of cv2 imports. It’s at site-packages/cv2/cv2.abi3.so.

otool -L site-packages/cv2/cv2.abi3.so

# We see a lot of `/System/Library` paths
# these are dependencies which are provided by the kernel
# we are not interested in them for now
# I've only added the direct dependencies we care about

/Users/hariomnarang/miniconda3/envs/linkers/lib/python3.9/site-packages/cv2/cv2.abi3.so:
        @loader_path/.dylibs/libavif.16.3.0.dylib
        @loader_path/.dylibs/libavformat.61.7.100.dylib
        @loader_path/.dylibs/libavcodec.61.19.101.dylib
        @loader_path/.dylibs/libswscale.8.3.100.dylib
        @loader_path/.dylibs/libavutil.59.39.100.dylib
        # .... other system dependency paths

These are now neither absolute nor relative paths. They don’t even look like actual paths (although the representation is very path-like). What’s @loader_path?

For every LC_LOAD_DYLIB command, dyld expands the path of each dependency using some rules. It provides three variables: @loader_path, @executable_path, and @rpath, which it dynamically resolves during runtime.

@loader_path expands to the parent directory of the object file that dyld is analyzing. @executable_path expands to the main executable’s parent directory path (in our case, this is the directory python resides in).

This capability is remarkable. While compiling object files, we can point to dependencies relative to the current object file. This allows us to ship applications that would have all their dependencies packaged in the distribution.

Concrete steps:

My cv2.abi3.so exists at /<path-to-site-packages>/cv2/cv2.abi3.so.
@loader_path resolves to /<path-to-site-packages>/cv2.
The dependency @loader_path/.dylibs/libavcodec.61.19.101.dylib resolves to /<path-to-site-packages>/cv2/.dylibs/libavcodec.61.19.101.dylib.
Running ls, I can see that this file exists in my system.

If you look closely at the OpenCV installation, it would have a directory .dylibs in the top level of the package. Running ls on it, we see a lot of shared libraries.

$ ls /Users/hariomnarang/miniconda3/envs/linkers/lib/python3.9/site-packages/cv2/.dylibs

libSvtAv1Enc.3.0.2.dylib        libcjson.1.7.18.dylib           liblcms2.2.dylib                libsharpyuv.0.1.1.dylib         libvmaf.3.dylib
libX11.6.dylib                  libcrypto.3.dylib               liblzma.5.dylib                 libsnappy.1.2.2.dylib           libvorbis.0.dylib
libXau.6.dylib                  libdav1d.7.dylib                libmbedcrypto.3.6.3.dylib       libsodium.26.dylib              libvorbisenc.2.dylib
libXdmcp.6.dylib                libfontconfig.1.dylib           libmp3lame.0.dylib              libsoxr.0.1.2.dylib             libvpx.11.dylib
libaom.3.12.1.dylib             libfreetype.6.dylib             libnettle.8.10.dylib            libspeex.1.dylib                libwebp.7.1.10.dylib
libaribb24.0.dylib              libgmp.10.dylib                 libogg.0.dylib                  libsrt.1.5.4.dylib              libwebpmux.3.1.1.dylib
libavcodec.61.19.101.dylib      libgnutls.30.dylib              libopencore-amrnb.0.dylib       libssh.4.10.1.dylib             libx264.164.dylib
libavformat.61.7.100.dylib      libhogweed.6.10.dylib           libopencore-amrwb.0.dylib       libssl.3.dylib                  libx265.215.dylib
libavif.16.3.0.dylib            libhwy.1.2.0.dylib              libopenjp2.2.5.3.dylib          libswresample.5.3.100.dylib     libxcb.1.1.0.dylib
libavutil.59.39.100.dylib       libidn2.0.dylib                 libopus.0.dylib                 libswscale.8.3.100.dylib        libzmq.5.dylib
libbluray.2.dylib               libintl.8.dylib                 libp11-kit.0.dylib              libtasn1.6.dylib
libbrotlicommon.1.1.0.dylib     libjxl.0.11.1.dylib             libpng16.16.dylib               libtheoradec.1.dylib
libbrotlidec.1.1.0.dylib        libjxl_cms.0.11.1.dylib         librav1e.0.8.0.dylib            libtheoraenc.1.dylib
libbrotlienc.1.1.0.dylib        libjxl_threads.0.11.1.dylib     librist.4.dylib                 libunistring.5.dylib

The OpenCV authors have been kind to their users now. They are shipping all the dependencies in a subdirectory .dylibs.
All files in .dylibs in turn also use @loader_path for their own dependencies.

$ otool -L /Users/hariomnarang/miniconda3/envs/linkers/lib/python3.9/site-packages/cv2/.dylibs/libavcodec.61.19.101.dylib

# I've skipped a lot of output
/Users/hariomnarang/miniconda3/envs/linkers/lib/python3.9/site-packages/cv2/.dylibs/libavcodec.61.19.101.dylib:
        @loader_path/libvorbis.0.dylib
        @loader_path/libvorbisenc.2.dylib
        @loader_path/libwebp.7.1.10.dylib

And these dependencies in turn do the same. Each uses their own @loader_path expansion to correctly define its dependencies deterministically. This makes the installation isolated, allowing us to place the package anywhere and it would just work.

@rpath

There is one final variable that dyld expands: @rpath. An example helps.

# a random dylib in my system
otool -l libmenu.dylib

Load command 12
          cmd LC_LOAD_DYLIB
         name @rpath/libncursesw.6.dylib

# only the relevant parts in the output
Load command 16
          cmd LC_RPATH
      cmdsize 32
         path @loader_path/

# only the relevant parts in the output
Load command 17
          cmd LC_RPATH
      cmdsize 32
         path /usr/local/lib

This dylib has a new load command type: LC_RPATH.

dyld would expand @rpath in each LC_LOAD_DYLIB to the value in LC_RPATH. If there are multiple LC_RPATH commands, it would expand using each RPATH value and return the first path that exists.
You can use @loader_path and @executable_path in LC_RPATH.
The command @rpath/libncursesw.6.dylib expands to @loader_path/libncursesw.6.dylib and /usr/local/lib/libncursesw.6.dylib, the linker loads the file that exists.

@rpath provides an extra level of indirection. A pattern is to use @rpath/<dep-name>.so for each dependency and set correct rpaths using LC_RPATH. Since we can add multiple LC_RPATH commands, it increases the search space the linker uses.

search order

dyld approximately does these steps (in order) for searching. This is a stripped-down version.

man dlopen is the source of truth. I’m skipping Mac frameworks and a lot of other environment variables here.

Search the leaf name in DYLD_LIBRARY_PATH
If its not a path like component (simply specifying the library name in load command), search in the current directory
Expand @rpath, @executable_path, @loader_path for each path-like dependency. If its a relative path, use the current directory to resolve.
Search the leaf name in DYLD_FALLBACK_LIBRARY_PATH, for older binaries, the default is /usr/local/lib:/usr/lib. You should not rely on it for your dependencies though

If a file exists at any step, it is loaded. If the linker cannot find the dependency, loading fails.

Comparison with ELF (Linux)

The Linux search order is slightly similar to macOS. I’m going to briefly explain the similarities and differences for each step described in the previous section. It’s useful to read the macOS section to understand the basics.

Reading the dependencies of a file (equivalent of otool). We will use readelf.

$ readelf -d cv2.cpython-39-aarch64-linux-gnu.so

Dynamic section at offset 0x18d0000 contains 43 entries:
  Tag        Type                         Name/Value
 0x000000000000000f (RPATH)              Library rpath: [$ORIGIN/../opencv_python.libs]
 0x0000000000000001 (NEEDED)             Shared library: [libpng15-7864b8f1.so.15.13.0]
 0x0000000000000001 (NEEDED)             Shared library: [libavcodec-f07f0976.so.58.112.103]
 0x0000000000000001 (NEEDED)             Shared library: [libavformat-714656c6.so.58.64.100]
 0x0000000000000001 (NEEDED)             Shared library: [libavutil-bfd36067.so.56.60.100]
 0x0000000000000001 (NEEDED)             Shared library: [libswscale-3ab36cb1.so.5.8.100]
 0x0000000000000001 (NEEDED)             Shared library: [libQt5Widgets-979a72e5.so.5.15.0]
 0x0000000000000001 (NEEDED)             Shared library: [libQt5Gui-efa77b9d.so.5.15.0]
 0x0000000000000001 (NEEDED)             Shared library: [libQt5Test-2c13d126.so.5.15.0]
 0x0000000000000001 (NEEDED)             Shared library: [libQt5Core-80f09a8a.so.5.15.0]
 0x0000000000000001 (NEEDED)             Shared library: [libz-558a5e64.so.1.2.7]
 0x0000000000000001 (NEEDED)             Shared library: [libpthread.so.0]
 0x0000000000000001 (NEEDED)             Shared library: [libdl.so.2]
 0x0000000000000001 (NEEDED)             Shared library: [libstdc++.so.6]
 0x0000000000000001 (NEEDED)             Shared library: [libm.so.6]
 0x0000000000000001 (NEEDED)             Shared library: [libgcc_s.so.1]
 0x0000000000000001 (NEEDED)             Shared library: [libc.so.6]
 0x0000000000000001 (NEEDED)             Shared library: [ld-linux-aarch64.so.1]

There are two kinds of entries here: RPATH and NEEDED (they are called DT_RPATH and DT_NEEDED in literature too).
The linker would try to find all the NEEDED entries.
- If the entry is path-like, then the linker assumes it’s a relative or absolute path and tries to directly load it.
- If the entry is simply a library name (not path-like), the linker would try to find that library in the RPATH.
  - RPATH is simply colon-separated path-like entries. Each path can contain an extra variable called $ORIGIN.
  - $ORIGIN would be set to the parent directory of the current object file. The linker would expand this variable to resolve the path.
  - $ORIGIN is similar to @loader_path in macOS.
  - The linker would also search in colon-separated directories in the environment variable LD_LIBRARY_PATH (similar to DYLD_LIBRARY_PATH in macOS).

That’s it at a bird’s eye view. You can take a look at man ld.so for more details in the search order.

DT_RPATH vs DT_RUNPATH

There are actually two kinds of RPaths in ELF files. DT_RPATH is deprecated and is mainly a historical thing, many libraries use it though :)
The detail is in how the searching happens. First, we consider the search order.

search in DT_RPATH (if there is no entry called DT_RUNPATH, else skip this check)
Search using LD_LIBRARY_PATH
search in DT_RUNPATH

The second difference is in how the RPath is set. It’s best to explain using an example.

# A -> B means A depends on B

./A -> ./B -> ./C
./D -> ./E

A.DT_RPATH = $ORIGIN/A/
B.DT_RPATH = $ORIGIN/B/
C.DT_RPATH = $ORIGIN/C/
D.DT_RPATH = $ORIGIN/D/
E.DT_RPATH = $ORIGIN/E/

For each file, the linker would search in directories as follows

Object file	Search directories
A	./A
B	./A ./B
C	./A ./B ./C
D	./D
E	./D ./E

The Linux linker uses the RPaths for all the ancestors of the object file it is currently analyzing.
If you imagine this as a graph, the set of RPaths used for searching is the union of all RPaths of all the ancestors (recursively) analyzed to reach this file. The order of how the linker reached this file matters now.

DT_RUNPATH is much simpler. The linker only uses the RUNPATH entry in the object file. It does not care about other files at all (similar to macOS).

search order

This is again a stripped down version, check man ld.so for the full version.

If DT_NEEDED is path-like, directly try to load using the path (can be relative or absolute, relative paths are resolved using current working directory)
Else
- If the binary does not have DT_RUNPATH but has DT_RPATH, search in those directories.
- LD_LIBRARY_PATH
- DT_RUNPATH
- Check ldconfig cache (you can query it by running the command ldconfig -p).
- Default paths: /usr/lib, /lib.

Changing dependencies

Given an object file, you could change the list of its dependencies quite easily. Consider the problem of changing our older installation of OpenCV which depended on ffmpeg@4. Our goal is to create a single folder that works similar to the newer version, where all the dependencies have been packaged and shipped along with the object file cv2.abi3.so (note that the older file is called cv2.cpython-39-darwin.so).

The main problem is load commands which use absolute paths.

Load command 12
          cmd LC_LOAD_DYLIB
      cmdsize 80
         name /opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib (offset 24)
   time stamp 2 Thu Jan  1 05:30:02 1970
      current version 58.134.100
compatibility version 58.0.0

We want to change this to @loader_path/.dylibs/libavcodec.58.dylib for macOS.
We can do this using install_name_tool (pre-installed with Xcode Command Line tools).

install_name_tool -change \
    '/opt/homebrew/opt/ffmpeg/lib/libavcodec.58.dylib' \
    '@loader_path/.dylibs/libavcodec.58.dylib' \
    ./cv2.cpython-39-darwin.so

For linux, you can add a new entry in DT_RUNPATH using patchelf.

# NOTE: the file in linux would be different for our example
# I'm just putting the syntax out there for this one
patchelf --add-rpath \
    '$ORIGIN/.dylibs' \
    ./cv2.cpython-39-darwin.so

# you can replace DT_NEEDED using
patchelf --replace-needed '<old-entry>' '<new-entry>' ./cv2.cpython-39-darwin.so

You would need to do this process for libavcodec.58.dylib and its dependencies too. Do this recursively for ALL the dependencies of cv2.cpython-39-darwin.so.

This ability is key to creating relocatable isolated distributions from an existing developer machine. It is used by many Python application packagers to create isolated folders.

Symbol resolution

We have seen how the linker searches for an object file’s dependencies (which are themselves object files). After discovery, the object file should be able to use the functions or variables defined in its dependencies.
Roughly, symbols can be considered the “interface” of a shared library. A symbol can be a function name, it can be a global variable name, and so on.

Each shared library has a symbol table. You can use the nm utility to see all the symbols exposed by an object file.

$ nm site-packages/cv2/cv2.abi3.so | tail

00000000010a9574 t _ycc_rgb_convert
00000000010424a4 t _ycck_cmyk_convert
0000000001090f64 t _ycck_cmyk_convert
00000000010ab268 t _ycck_cmyk_convert
0000000001871850 s _z_errmsg
000000000128b864 t _zcalloc
000000000128b86c t _zcfree
00000000014a8fc4 s _zeroruns
000000000186b050 s _zipFields
                 U dyld_stub_binder

The dependent object file would have stub (dummy) statements for all the references of symbols it does not contain. The linker is responsible for replacing those with the correct addresses.
The problem is simple enough to understand: given an object file and a set of its dependencies, replace all stubs in the object files with the correct addresses found from the dependencies. This is called symbol resolution.

what about clashes?

What if two libraries provide the same symbol name? Which definition wins?
The answer to this is actually pretty interesting, and it was not what I had assumed it would be at all.
I will first discuss the simple case: Linux. macOS has a more sophisticated symbol resolution process, and it is amazing :)

I will use a hypothetical example here.

# `left -> right` means left depends on right
a.out -> libA.so -> libC.so
      -> libB.so -> libD.so

# both libE.so differ slightly,
libC.so -> ../C/libE.so
libD.so -> ../D/libE.so

In the example above, libA.so and libB.so both define a symbol called direct_clash. libC.so and libD.so also both define a common symbol called transitive_clash.
libC.so depends on ../C/libE.so and libD.so depends on ../D/libE.so. Although the library names are same, they have different content. For the sake of this example, ../D/libE.so has an extra symbol called extra_symbol.

The whole set of libraries that a.out depends on transitively will be called the dependency closure (libA.so, libB.so, libC.so, libD.so, ../C/libE.so, ../D/libE.so in this case).

Linux

The Linux linker would arbitrarily pick a single definition for every clash. This is mostly the library that is first loaded in the linker. It would happen for both direct_clash and transitive_clash. The linker maintains a flat namespace for all symbols.
Flat namespaces are bad. All the symbols defined by any shared library should be unique in the whole dependency closure.

Another problem is that the linker only maintains one copy of symbols for every library it ever loads. If ../C/libE.so is loaded first, ../D/libE.so won’t be loaded. This will break symbol resolution for libD.so (as its actual dependency is not really loaded).
This is a far-fetched example, but this might happen if you depend on different versions of the same library transitively.

The macOS linker is more complicated and solves many of the problems above.

macOS

macOS does not maintain a flat namespace for symbols (yayy).

If there is a symbol clash in direct dependencies of any object file, then the winner is arbitrary (the first one to load most likely). In our case, a.out would only see a single definition of direct_clash. This is similar to importing the same name in a Python file from different modules (although in the case of Python, the last imported symbol wins).
For all the other cases, there is no clash. transitive_clash won’t clash. libA.so will see the definition in libC.so, libB.so will see it in libD.so.

The same holds true for loading libraries with the same name but different content. If it is not done by any direct dependency, we are good. You can imagine the macOS linker maintaining a table for symbol resolution separately for each shared library.

This is why you can’t put every shared library in a single folder and set it in DYLD_LIBRARY_PATH. In the wild, you might have multiple library definitions with the same name while having symbol clashes (especially in the Python ecosystem).

Packaging

As we saw above, since the macOS linker does not maintain a flat namespace, defining a folder structure while packaging your application for distribution is slightly more tricky.

We will use the same example as we used in the Symbol Resolution section.

# `left -> right` means left depends on right
a.out -> libA.so -> libC.so
      -> libB.so -> libD.so

# both libE.so differ slightly,
libC.so -> ../C/libE.so
libD.so -> ../D/libE.so

the first structure

The structure we could start out with could be

a.out
libs
    libA.so
    libB.so
    Adeps
        libC.so
        Cdeps
            libE.so
    Bdeps
        libD.so
        Ddeps
            libE.so

We would need to patch each library to point to the correct dependency (libA.so would have an entry @loader_path/Adeps/libC.so in macOS, in Linux we would simply set DT_RUNPATH=$ORIGIN/Adeps)
This works, but it can quickly get very unwieldy in the case of a large set of dependencies. We might also end up with duplicate file copies if two object files depend on the same dependency, costing us disk space.

A better way

We have two goals:

Minimize nesting while allowing the macOS linker to provide a nested namespace (using a flat structure which mimics nested structures)
Minimize copying (using symlinks)

The structure I came up with is very similar to how pnpm does it for node_modules.
Although I didn’t have this in mind while finding a structure for my application, I naturally ended up with a similar one (reinventing the wheel is a hobby now 😭).

# `->` is a symlink here
reals
    r
        libA-1a2b3c4d5e.so
        libB-6f7g8h9i0j.so
        libC-2b4d6f8h0j.so
        libD-3c5e7g9i1k.so
        libE-4d6f8h0j2l.so
        libE-5e7g9i1k3m.so
        a-1231fwsdkjjv1.out
symlinks
    libA-1a2b3c4d5e.so
        libC.so -> ../../reals/r/libC-2b4d6f8h0j.so
    libB-6f7g8h9i0j.so
        libD.so -> ../../reals/r/libD-3c5e7g9i1k.so
    libC-2b4d6f8h0j.so
        libE.so -> ../../reals/r/libE-4d6f8h0j2l.so
    libD-3c5e7g9i1k.so
        libE.so -> ../../reals/r/libE-5e7g9i1k3m.so
    a-1231fwsdkjjv1.out
        libA.so -> ../../reals/r/libA-1a2b3c4d5e.so
        libB.so -> ../../reals/r/libB-6f7g8h9i0j.so
bin
    b
        a.out -> ../../reals/r/a-1231fwsdkjjv1.out

All the shared libraries are kept in the reals/r directory.
- The first thing you notice is that we also attach random hashes to file names along with their names. This is to make sure the two different libE.so do not clash.
For every shared library in reals/r, we have a directory of the library’s name in symlinks folder (symlinks/libA-1a2b3c4d5e.so as an example).
- This is the folder which contains all the direct dependencies of the corresponding file in the reals/r directory.
- As an example, we have a symlink libC.so in symlinks/libA-1a2b3c4d5e.so pointing to the actual libC.so in the reals/r directory
We use ../../symlinks/libA-1a2b3c4d5e.so as the LC_RPATH for the object file @loader_path/../../libA-1a2b3c4d5e.so (for Linux we set DT_RUNPATH to $ORIGIN/../../libA-1a2b3c4d5e.so).
- All dependencies are specified using this RPath.
- For macOS, there would be one LC_LOAD_DYLIB command @rpath/libC.so. For Linux, we simply have libC.so as a DT_NEEDED entry.

That’s about it. The algorithm and code to generate this structure is also remarkably easy since it’s a flat structure.

Why use `reals/r` instead of `reals`

There is one extra weird detail: I’m using reals/r as the base directory for all real object files. Why the extra directory depth?
Let’s consider how the linker would load libA.so for a.out.
I’m doing this for macOS, but since the scheme is the same for Linux, the steps should be easy to translate.

a.out has RPath = @loader_path/../../symlinks/a-1231fwsdkjjv1.out. The loader tries to load libA.so
The RPath for libA.so is set to @loader_path/../../symlinks/libA-1a2b3c4d5e.so

Now, what is the value of @loader_path that the linker uses ($ORIGIN in Linux)?
Is it the path of the symlink symlinks/a-1231fwsdkjjv1.out/libA.so? Or is it the real path reals/r/libA-1a2b3c4d5e.so?
It’s the real path in the case of macOS and the symlink path in the case of Linux.

The crux of the problem is that Linux/macOS use different strategies for assigning the value of $ORIGIN/@loader_path.
In the case of Linux, it is the path it loaded the library from; it does not matter if it’s a symlink.
macOS would use the real path.

It does not matter what the linker does for us, because the path ../../symlinks/libA-1a2b3c4d5e.so points to the same location regardless.

@loader_path/../../symlinks/libA-1a2b3c4d5e.so resolves to reals/r/../../symlinks/libA-1a2b3c4d5e.so
$ORIGIN/../../symlinks/libA-1a2b3c4d5e.so resolves to symlinks/a-1231fwsdkjjv1.out/../../symlinks/libA-1a2b3c4d5e.so

We basically keep all the files at the same depth from the root of the package.

The Python Packaging Problem

CPython (the most popular Python interpreter implementation) allows developers to create shared libraries and load them directly in the Python process.
It also has a very good FFI interface, allowing compiled code to interact with native Python objects. This is extremely common in the wild. Python has good documentation for it too. It’s kind of a first-class citizen of the ecosystem. They call it “extending the Python interpreter”.
It also has a really flexible import system. You could even write your own way of importing modules using ad-hoc algorithms.

Providing a good FFI has allowed developers to be productive with Python while having native machine code speeds for the hot paths.

The flip side of this is that the package maintainer needs to find a good way to ship these shared libraries. Many of them, however, do not provide isolated folders containing all the required dependencies (as seen in older versions of OpenCV; they fixed it in the latest).
Library developers are increasingly providing these isolated structures. All the major libraries I’ve used do this.

Some advertising: I wrote this article while researching and developing shenzi, a greedy Python standalone bundler.
A lot of details are from that code.

Why is it hard to make Python apps relocatable

sys.path is an important variable in every Python process which allows module discovery. It’s a list of directories which Python uses to find packages. If you do import torch, Python would find a directory called torch in all the directories in sys.path and load torch/__init__.py in the process.

Theoretically, you could put your Python code and all the code in your sys.path in a single folder, along with the main Python executable. If the Python executable does not depend on any dynamic libraries and if all the code is pure Python code (including pip packages you installed), this would work.

The Python interpreter is not statically linked; you can’t load extensions otherwise.
Python packages use dlopen to link to shared libraries dynamically.
Python has some heuristics to find its own standard library (and that library also has a bunch of C extensions, described here in this code).
Transitively, your packages can depend on any shared libraries outside your sys.path. In this case, you need to package those in your folder too.
Linkers have a huge search space and are extremely flexible. You could give a linker a simple name for linking and it would search many locations on your computer for this. The ecosystem and developers rely on this flexibility for their dependencies. The flexibility is a footgun when you want to ship everything deterministically.

Creating relocatable Python applications

The first step is to find the set of all shared libraries that a Python process is loading. You can do this by running the application and tracing all the dlopen calls (there are also C extensions which provide a different dlopen interface; you would need to track them too).
Recursively find the whole dependency closure of all the loaded libraries (and the Python executable too)
It is also useful to intercept sys.path, find all the shared libraries in all the pip packages, and recursively find their dependency closure
At this point, you have a graph of all the shared libraries that the Python process can load.
Dump all the shared libraries in your distribution folder, patch these libraries using the algorithm described in Packaging
Dump the contents of sys.path (all the installed packages) to the standalone folder. Replace all shared libraries with symlinks to their real paths
All the libraries which are opened using dlopen need to be visible to the linker. We need to put symlinks to those in a folder which is kept in DYLD_LIBRARY_PATH/LD_LIBRARY_PATH. You need to be careful to not add random libraries in this folder.
Dump the standard library at a location the interpreter can find it
Dump the interpreter after patching it using the algorithm in Packaging.
Add a startup script which sets up relevant environment variables for starting the interpreter.

It is extremely important to follow the order the linker loaded the libraries in the developer machine as faithfully as you can. You need to retrace the steps the linker took to create this graph; otherwise, you end up with some hard-to-debug problems (and due to the nature of DT_RPATH in Linux).

That’s about it. From what I understand, most of the Python standalone application creators use a version of the above algorithm, with differences in the implementation and structure.

Wrapping up

I’ve tried to cover a lot of ground on how the linker searches dependencies to stitch together our programs. I went into some details of the annoying stuff from time to time; I hope they weren’t that boring.
I’m adding some references if someone wants more details, the ones that I’ve noted down at least.

References

macOS

man dlopen
man dyld
https://clarkkromenaker.com/post/library-dynamic-loading-mac/
https://www.jviotti.com/2023/11/20/exploring-macos-private-frameworks.html
https://github.com/Karmaz95/Snake_Apple (A lot of cool articles)

Linux

man ld.so
https://linux-audit.com/elf-binaries-on-linux-understanding-and-analysis/
https://lwn.net/Articles/276782/ (Article series by the Gold linker developer, pretty big, haven’t read all of it)

Table of Contents

The problem

Basic anatomy of compiled code

Dependencies of a Mach-O file

DYLD_LIBRARY_PATH

absolute paths are a problem

@loader_path, @executable_path

@rpath

search order

Comparison with ELF (Linux)

DT_RPATH vs DT_RUNPATH

search order

Changing dependencies

Symbol resolution

what about clashes?

Linux

macOS

Packaging

the first structure

A better way

Why use reals/r instead of reals

The Python Packaging Problem

Why is it hard to make Python apps relocatable

Creating relocatable Python applications

Wrapping up

References

macOS

Linux

Why use `reals/r` instead of `reals`
